अगर आप construction industry से जुड़े हैं तो आपने IS 1200 का नाम जरूर सुना होगा। Bureau of Indian Standards (BIS) द्वारा जारी यह standard भारत में किसी भी construction project की measurement के लिए बेहद जरूरी document है।
IS 1200 Part 1:1992 खासतौर पर earthwork यानी मिट्टी के काम की measurement को define करता है। यह standard पहली बार 1960s में publish हुआ था और 1992 का version इसका चौथा revision है, जिसे 2002 और 2022 में फिर से confirm किया गया है।
Construction projects में सही measurement सिर्फ एक technical formality नहीं है – यह पूरे project की financial transparency और success को decide करता है।
Items को एक साथ club किया जा सकता है, बशर्ते कि detailed description के basis पर break-up पर agreement हो। यह construction work में flexibility provide करता है।
Dimensions को record करते समय order यह होना चाहिए:
यह sequence हर जगह consistent होना चाहिए।
IS 1200 के तहत सभी measurements decimal system में होनी चाहिए:
यह precision construction quality को ensure करने में मदद करती है।
निम्नलिखित conditions में work को separately measure करना चाहिए:
Important: High और low water tides के levels को clearly state किया जाना चाहिए।
BOQ में materials और workmanship का complete description होना चाहिए और execute किए जाने वाले work को accurately represent करना चाहिए।
निम्नलिखित works को separately नहीं measure किया जाएगा और इनके लिए allowance main item के description में include माना जाएगा:
Required से ज्यादा कोई भी special pumping को separately measure किया जाएगा। इसमें tube well/well point dewatering भी include है, जहाँ resort किया जाता है।
Earthwork measurement में सबसे critical aspect soil type की पहचान है। IS 1200 soil को चार main categories में classify करता है:-
Generally कोई भी soil जो pick और shovel या PHAWRA, rake या दूसरे ordinary digging implements के normal application से निकल जाती है। यह सबसे common type है और अधिकांश residential construction में पाई जाती है। इसमें शामिल हैं:
Generally कोई भी soil जिसको loosen करने के लिए picks या jumpers या scarifiers के close application की requirement होती है:
Soil और water का mixture जो fluid या weak solid state में हो।
Rock या rock boulders जिन्हें crowbars से quarry या split किया जा सकता है। इसमें laterite और hard conglomerate भी include हैं।
Excavation के लिए कोई भी rock या boulder जिसके लिए blasting की requirement होती है।
Note: Boulder generally weathering, disintegration और water या ice से abrasion द्वारा rounded हुआ rock का fragment है, जिसका diameter किसी भी direction में 300 mm से अधिक होता है।
Hard rock जिसमें normally blasting की requirement है लेकिन किसी reason से blasting prohibited है और excavation को chiselling, wedging या किसी दूसरी agreed method से करना होता है।
जहाँ hard/dense soil, soft/disintegrated rock और hard rock mixed हों, measurement method (a) और/या (b) द्वारा किया जाएगा।
Earthwork की measurement cubic metres में की जाएगी, unless otherwise mentioned हो। Measurement उन dimensions की होगी जिनसे soil निकाली गई है और bulk में increase के लिए कोई allowance नहीं होगा।
Excavation की measurement निम्नानुसार की जाएगी:
जब excavation fairly uniform ground में trenches या borrow pits में हो, तो measurement cutting trenches या borrow pits का किया जाएगा। ‘Dead men’ या ‘tell-tales’ को average depth determine करने के लिए suitable intervals पर छोड़ा जा सकता है।
जहाँ ground uniform नहीं है, levels को start से पहले, clearance के बाद और work की quantity complete होने के बाद लिए जाने चाहिए। Excavation की quantity इन तीनो levels से calculate की जाएगी।
जहाँ soft/disintegrated rock और hard rock mixed हों, total quantity का measurement method (a) और/या (b) द्वारा किया जाएगा।
जहाँ hard/dense soil, soft/disintegrated rock और hard rock mixed हों, total quantity के लिए Hard rock excavated को stack करके अलग से measure करें . Hard rock quantity को mixture से deduct करें . Soft/disintegrated rock separately calculate करें
Filling का actual measurement site clearance के बाद और compaction के बाद suitable intervals पर original ground के levels लेकर calculate किया जाएगा।
Floors के case को छोड़कर सभी cases में filling के actual measurements से deductions किए जाएंगे। Deduction pre-accepted या specified (percentage के रूप में) basis पर होगी।
अगर borrow pits से filling obtain की जाती है, तो इसे borrow pits से measure किया जाना चाहिए और excavation के रूप में describe किया जाना चाहिए।
150 mm से अधिक deep नहीं जाने वाली natural ground की trimming, excavated surface और filled up area को vegetation और/या small inequalities remove करने के लिए surface dressing के रूप में describe किया जाएगा और square metres में measure किया जाएगा।
Sides और bottom की dressing की requirement नहीं वाली और exact levels तक reduction की requirement नहीं वाली excavation को rough excavation के रूप में describe किया जाएगा और cubic metres में measure किया जाएगा।
1.5 m से अधिक width और 10 m² on plan लेकिन 300 mm से अधिक depth नहीं वाली excavation को ‘surface excavation’ के रूप में describe किया जाएगा और square metres में measure किया जाएगा।
1.5 m से अधिक width और 10 m² on plan, और 300 mm depth में excavation को ‘excavation over area’ के रूप में describe किया जाएगा और cubic metres में measure किया जाएगा।
Foundations और pipes, cables आदि के लिए trenches में excavation जो 1.5 m से अधिक width में नहीं है और shafts, wells, cesspits के लिए और plan पर 10 m² से अधिक नहीं है, को cubic metres में describe और measure किया जाएगा।
Authorised working space के basis पर calculate की गई authorised quantities या actually excavate की गई quantities को measure किया जाएगा।
Authorised Working Space: Substructure के face से 600 mm measure किया जाएगा जहाँ extra working space की requirement है।
1 m से अधिक depth के लिए, trench की प्रत्येक side 50 mm/m depth का allowance specified width में add किया जाएगा। यह provision sides को properly work करने के लिए space देता है।
0.5 m² से अधिक न होने वाले independent post holes (या similar holes) को enumerate किया जाएगा और description में return, fill और ram करना और surplus spoil को remove करना include होगा।
Excavation की item के साथ describe नहीं की गई excavated earth की returning, filling और ramming को cubic metres में measure किया जाएगा और 200 mm से अधिक depth में नहीं जाने वाली layers में spreading, watering, well ramming और levelling include होगा।
Embankments form करना और levels बनाने के लिए filling को cubic metres में measure किया जाएगा और इसमें slopes का formation include होगा। अगर material layers में deposit की जानी है, तो ऐसी layers की thickness state की जाएगी। Consolidation की method describe की जाएगी।
Floors के नीचे filling को cubic metres में measure किया जाएगा और इसमें 200 mm से अधिक depth में नहीं जाने वाली layers में spreading, watering, well ramming और levelling include होगा।
Removal के लिए distance को shortest practicable route पर measure किया जाएगा:
Categories:
5.1.1: Description में loading और unloading शामिल करें।
5.1.2: Re-handling के लिए spoil heaps जो consolidated हो गए हों, separately measure होंगे और reason state करना होगा।
5.1.3: Lead measurement के लिए excavated area को suitable blocks में divide करें, और प्रत्येक block के centre से placed earth के centre तक distance लें।
Lift को ground level से measure किया जाएगा। Ground level से 1.5 m depth तक excavation और ground पर excavated material deposit करना various types की soil के लिए earthwork में include होगा।
Extra Lift: 1.5 m या उसके part की unit में measure की जाएगी।
Important Note: जब earth को bank/obstruction के ऊपर carry करना हो और उसके beyond dump करना हो, तो lift excavated earth के centre of gravity और bank/obstruction के top के बीच level में difference होगी।
Excavation के face को support देने के लिए required planking और strutting को face के square metres में measure किया जाएगा और 1.5 m की stages में grouped और separately measure किया जाएगा।
सभी necessary timber work का use और waste, जिसमें wales, struts और open या close poling boards, उनकी fixing और subsequent removal include है।
निम्नलिखित को separately measure किया जाएगा:
जहाँ tightly driven close लेकिन jointed sheeting necessary है (जैसे running sand के case में), item को separately measure किया जाएगा और sheeting के behind cavities को fill करने में suitable material include होगी।
Permanently position में left होने के लिए required planking और strutting को separately measure किया जाएगा।
300 mm से अधिक girth वाले shrubs, brushwood, small trees की clearing को square metres में measure किया जाएगा और इसमें removal और disposal include माना जाएगा। Girth ground level से 1 m above measure की जाएगी।
Hedges को cut करना और fences को remove करना fully describe किया जाएगा और running metres में measure किया जाएगा और इसमें removal और disposal include माना जाएगा।
300 mm girth और 1000 mm girth तक के trees को cut करना एक item के रूप में enumerate किया जाएगा और girth state की जाएगी। 1000 mm से अधिक girth वाले trees को cut करना girth state करते हुए separately enumerate किया जाएगा। Girth ground level से one metre above measure की जाएगी। Item में branches को lop करना और removal और disposal include होगा।
Stacking सहित roots को dig करना separately measure और enumerate किया जाएगा।
IS 1200 (Part 1): 1992 standard construction industry में earthwork के accurate measurement के लिए एक comprehensive guide provide करता है। इन guidelines को follow करके, contractors और engineers ensure कर सकते हैं कि सभी earthwork properly measure और document किया गया है।
यह standard transparency ensure करता है और construction projects में disputes को reduce करने में help करता है। Proper measurement से:
Q1: IS 1200 Part 1 का latest version कौन सा है?
IS 1200 Part 1:1992 (Fourth Revision) जिसे 2022 में reaffirm किया गया है।
Q2: क्या यह standard सभी projects के लिए mandatory है?
Government projects में definitely mandatory है। Private projects में recommended है और बड़े developers follow करते हैं।
Q3: Cobblestone की exact definition क्या है?
80mm से 300mm diameter के rounded या sub-rounded stone pieces जो naturally या artificially मिलें।
Q4: Excavation measurement की accuracy कितनी होनी चाहिए?
Volume measurement 0.01 cubic meter तक accurate होनी चाहिए। यानी दो decimal places तक।
Q5: Working space कब और कितना allow किया जाता है?
Formwork या damp-proofing के लिए additional space allow होता है, लेकिए sanctioned quantity से ज्यादा नहीं।
Q6: IS 1200 की copy कहां से मिलेगी?
Bureau of Indian Standards की official website (www.bis.gov.in) से online purchase कर सकते हैं।
Q7: Soft soil और hard soil में payment difference होता है?
हाँ, hard soil excavation की rate ज्यादा होती है क्योंकि extra effort और equipment चाहिए।
Q8: BOQ में items को club कब किया जा सकता है?
जब similar nature के works हों और contractor तथा client दोनों agree करें।
Q9 : Authorized working space क्या है?
A: Foundation excavation में substructure के face से 600 mm तक का extra space जो working के लिए provide किया जाता है। यह space workers को safely और efficiently काम करने में help करता है।
Disclaimer: यह article IS 1200 (Part 1): 1992 standard की general information के लिए है। Actual construction works के लिए, कृपया original standard document और qualified engineers से consult करें। हर project की specific requirements अलग हो सकती हैं।
