अगर आप Bihar के Power Transmission sector में काम करते हैं — चाहे आप एक Field Engineer हों, Estimation Expert हों, या Contractor — तो BSPTCL (Bihar State Power Transmission Company Limited) का Schedule of Rate (SOR) 2024-25 आपके लिए एक बेहद जरूरी document है।
यह SOR केवल एक price list नहीं है। यह Bihar की power transmission infrastructure के निर्माण, erection, और maintenance के लिए competent authority द्वारा approved standard rates का आधिकारिक framework है — जो Estimates बनाने से लेकर DPR तैयार करने तक हर जगह काम आता है।
इस article में हम इस SOR के हर important section को breakdown करके समझेंगे
Schedule of Rate (SOR) एक standardized document होता है जिसमें किसी organization द्वारा विभिन्न materials, equipment, और erection/commissioning कार्यों की indicative unit rates दी जाती हैं।
BSPTCL का यह SOR मुख्यतः तीन उद्देश्यों के लिए बनाया गया है:
BSPTCL SOR तीन बड़े खंडों में बँटा है:
| Section | विषय | Pages |
|---|---|---|
| C | Civil Works of Grid Sub-Station & Transmission Lines | 2 |
| D | Construction Work (Supply & Erection) — Transmission Lines & Sub-Stations | 3–39 |
| E | Maintenance Work (O&M) — GSS & Transmission Lines | 50–64 |
Section D सबसे विस्तृत है और इसमें 12 अलग-अलग schedule हैं — Transmission Lines से लेकर Telecom equipment तक।
अगर आप BSPTCL SOR 2024-25 को डाउनलोड करना चाहते है तो निचे दिए गए लिंक पर क्लिक करे
BSPTCL SOR – 2024-25 | 3 MB |
Transmission line construction के लिए supply component में सबसे पहला और बड़ा item है — Tower Steel।
| Item | Unit | Rate (₹) |
|---|---|---|
| High Tensile Steel (Tower Body) | MT | 1,14,049.95 |
| Mild Steel | MT | 1,10,558.70 |
| Hexagonal Bolts & Nuts (incl. Step bolts) | MT | 1,45,873.35 |
| Anti Theft Bolt | MT | 1,45,873.35 |
BSPTCL की 132 kV से 220 kV तक की lines में मुख्यतः तीन conductors use होते हैं:
| Conductor Type | Voltage Level | Rate per KM (₹) |
|---|---|---|
| ACSR Panther | 132 kV | 2,53,100.40 |
| ACSR Zebra | 220 kV | 4,36,453.50 |
| ACSR Moose | 132/220 kV | 4,87,792.20 |
| HTLS Conductor (equivalent to Panther) | 132 kV | 11,52,100.00 |
HTLS Conductor की rate सबसे अधिक है — लगभग Panther conductor से 4.5 गुना — लेकिन इसकी current carrying capacity कहीं अधिक होती है, जो reconductoring projects में ROI justify करती है।
| Insulator | Strength | Rate (₹/Nos.) |
|---|---|---|
| For Panther (132 kV) | 70 kN | 5,163.90 |
| For Panther (132 kV) | 90 kN | 5,539.80 |
| For Zebra (220 kV) | 120 kN | 5,914.65 |
| For Moose (400 kV) | 160 kN | 8,949.15 |
SOR 2024-25 में पहली बार Steel Monopole के लिए विस्तृत rates दी गई हैं — 220 kV और 132 kV दोनों के लिए। यह urban areas और narrow corridors में traditional lattice towers का बेहतर विकल्प है।
| Pole Type | Weight (kg) | Supply Rate (₹) | Erection Rate (₹) |
|---|---|---|---|
| D/C PC+0 (Suspension, 15–30°) | 13,522 | 39,50,735.25 | 4,44,874.50 |
| D/C PD+0 (Angle, 30–60°) | 18,618 | 49,47,130.65 | 5,21,230.50 |
| M/C MC+0 (Multi-circuit, 0–40°) | 41,760 | 1,23,38,842.95 | 13,05,486.00 |
| M/C MD+0 (Multi-circuit, 90°) | 62,770 | 1,68,01,157.10 | 20,66,778.00 |
Multi-circuit monopole का weight 62 MT से अधिक हो सकता है — इसलिए foundation design और soil investigation इसमें critical factor बन जाता है।
| कार्य | Unit | Rate (₹) |
|---|---|---|
| Complete route survey (profiling, spotting, check survey) | RKM | 33,269.25 |
| Soil Investigation (normal locations) | Nos. | 20,580.00 |
Complete tower erection (stub setting, tack welding, cross arm तक) की rate:
➡️ ₹17,106.60 per MT
| Stringing Category | Configuration | Rate (₹/RKM) |
|---|---|---|
| 132 kV Panther — S/C, 3 Phase | Normal | 1,37,997.30 |
| 132 kV Panther — 2nd Circuit (Live line) | Hot line | 3,44,996.40 |
| 132 kV D/C Panther — 6 Phase | D/C line | 2,75,997.75 |
| 220 kV Zebra — D/C, 6 Phase | D/C line | 3,30,799.35 |
| 220 kV Twin Moose — D/C, 12 nos. | D/C line | 6,61,598.70 |
| 132 kV HTLS — D/C, 6 Phase | D/C line | 9,59,011.50 |
Live line पर 2nd circuit stringing की rate normal stringing से 2.5 गुना अधिक है — जो hot line work की जटिलता और safety requirements को दर्शाती है।
यह SOR का सबसे महत्वपूर्ण और विस्तृत section है — 220/132/33 kV और 400 kV GIS sub-stations के लिए।
| Transformer | Capacity | Supply Rate (₹) | Erection Rate (₹) |
|---|---|---|---|
| 400/220/33 kV Auto Transformer | 500 MVA | 24,96,14,561.00 | 13,75,000.00 |
| 220/132/33 kV Auto Transformer | 200 MVA | 11,10,61,341.00 | 10,30,160.25 |
| 220/132/33 kV Auto Transformer | 160 MVA | 9,81,55,750.00 | 10,23,760.50 |
| 132/33 kV Power Transformer | 80 MVA | 7,20,00,000.00 | 6,36,646.50 |
| 132/33 kV Power Transformer | 50 MVA | 4,07,50,243.80 | 4,72,176.60 |
| Equipment | Specification | Supply Rate (₹) |
|---|---|---|
| SF6 Circuit Breaker (220 kV) | 2500 A, 40 kA | 19,23,673.50 |
| Isolator with 2 E/S (220 kV) | 1600 A, 40 kA | 7,16,864.40 |
| Current Transformer 5-core (220 kV) | 1600 A, 120% ext. | 4,69,006.65 |
| CVT (220 kV) | 4400 pF | 3,30,576.75 |
| Surge Arrester (220 kV) | 216 kV, Class III | 72,551.85 |
400 kV GIS sub-stations के लिए rates बेहद high हैं — इनका scope भी उतना ही बड़ा होता है:
| GIS Equipment | Spec. | Supply Rate (₹) |
|---|---|---|
| 420 kV SF6 GIS ICT Feeder Bay | 3150 A, 63 kA | 2,91,63,750.00 |
| 420 kV SF6 GIS Line Feeder Bay | 3150 A, 63 kA | 3,21,51,525.00 |
| 420 kV SF6 GIS Bus Bar Module | 3150 A, 63 kA | 1,23,27,000.00 |
| 125 MVAR Shunt Reactor (420 kV) | 3-Phase | 10,65,35,071.00 |
| 500 MVA Auto Transformer (400 kV) | 400/220/33 kV | 24,96,14,561.00 |
Modern transmission lines में OPGW (Optical Power Ground Wire) अनिवार्य component बन चुका है। यह Earth wire का काम करते हुए साथ में fiber optic communication भी provide करता है।
| Item | Unit | Supply Rate (₹) |
|---|---|---|
| 24 Fibre OPGW Cable (New line) | KM | 1,91,297.40 |
| 48 Fibre OPGW Cable | KM | 2,00,406.80 |
| 24 Fibre OPGW Cable (O&M works) | KM | 1,82,188.00 |
| Hardware Set (24F OPGW) | Set | 37,213.00 |
| Joint Box (24 Fibre) | No. | 30,175.00 |
| FODP 48F Indoor (rack mounted) | No. | 69,032.00 |
OPGW stringing की erection rate भी terrain के अनुसार vary करती है — plain area में ₹34,651.80/km से लेकर hill/interior area में ₹48,512.75/km तक।
Section E में GSS और Transmission Line की maintenance के लिए comprehensive rates दी गई हैं।
| कार्य | Unit | Rate (₹) |
|---|---|---|
| 132 kV SF6 CB Erection, Testing & Commissioning | Nos. | 42,458.45 |
| 220 kV CB Erection, Testing & Commissioning | Nos. | 1,00,249.11 |
| 50 MVA Transformer E,T&C | Nos. | 4,69,244.00 |
| 200 MVA Transformer E,T&C | Nos. | 11,70,000.00 |
| Transformer Oil Filtration (contractor’s machine) | Per ltr. | 6.84 |
| Treated Earth Pit Construction (4x10ft) | Nos. | 31,440.00 |
| कार्य | Unit | Rate (₹) |
|---|---|---|
| Insulator String Replacement (220 kV) | Each string | 9,641.21 |
| Insulator String Replacement (132 kV) | Each string | 8,677.45 |
| Broken conductor repair (re-jointing) | 1 No. | 9,641.21 |
| Tower erection (maintenance) | Per MT | 7,076.41 |
| Nut-bolt tightening (220 kV tower) | Per Tower | 1,831.14 |
| ERS Installation (complete) | Nos. | 2,37,325.90 |
BSPTCL SOR में Power Transformers की transportation के लिए भी detailed rates हैं — capacity-wise:
BSPTCL के SOR में Civil Works की rates directly include नहीं की गई हैं। इसके बजाय Preamble में clearly निर्देश दिया गया है:
यह hierarchy engineers के लिए estimate बनाते वक्त बेहद काम आती है।
इस वर्ष के SOR में कुछ नई items शामिल की गई हैं जो पिछले versions में नहीं थीं:
BSPTCL का यह Schedule of Rate 2024-25 Bihar के power transmission sector में काम करने वाले हर professional के लिए एक authoritative reference है। चाहे आप 132 kV line का estimate बना रहे हों, 400 kV GIS sub-station का DPR तैयार कर रहे हों, या किसी maintenance contract की costing कर रहे हों — यह document आपकी calculations का आधार है।
इस SOR की सबसे बड़ी खूबी यह है कि यह Supply और Erection दोनों को अलग-अलग cover करता है — जिससे Engineer को bill of quantities और payment terms दोनों के हिसाब से estimate split करने में आसानी होती है।
अगर आप BSPTCL में work करते हैं या bid करने की सोच रहे हैं — तो इस SOR को ध्यान से पढ़ें, समझें, और अपनी estimates में इसे सही तरीके से apply करें।
अस्वीकरण: यह article BSPTCL द्वारा जारी SOR 2024-25 document पर आधारित है। Actual tender participation से पहले official BSPTCL circular और latest amendments जरूर देखें।
